RHEOFALT® HP AM
100% Renewable RAP Rejuvenator – IIT Bombay Validated Technology for Circular Asphalt Economy
RHEOFALT® HP AM is BASF's 100% renewable RAP rejuvenator using advanced biopolymeric technology that isolates the polar effect of asphaltenes, enabling complete bitumen reusability. IIT Bombay validated for Indian conditions, it achieves up to 100% asphalt recycling with 28% CO₂ reduction (47.41 kg to 34.06 kg per ton). VUBS Corporation provides comprehensive technical support and ex-stock availability across India.
Understand in More Detail
This 100% renewable bio-based rejuvenator revolutionizes asphalt recycling technology, validated by IIT Bombay research. Enabling up to 100% RAP utilization while eliminating virgin bitumen dependence, it restores aged asphalt binder properties, reduces mixing temperatures, and delivers equivalent or superior performance to virgin asphalt. The bio-based chemistry supports circular economy principles and sustainable pavement construction. At VUBS Corporation, we provide comprehensive technical support for RHEOFALT® HP AM implementation, helping customers achieve cost savings, carbon reduction, and superior pavement performance through innovative RAP recycling technology.
Key Features
Applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Chemical Definition | Bio-Polymeric Resin (100% Natural Renewable Source) |
| Viscosity at 60°C | 1,500 - 2,500 cPs (Maximum 2,500 cPs) |
| Specific Gravity at 25°C | 0.985 (Range: 0.970 - 0.990) |
| Solid Content | 99.5 - 100% (Minimum 99%) |
| Appearance | Dark Brown Liquid |
| Flash Point | 248°C (Well above 200°C safety threshold) |
| Odor | Characteristic Natural Resin |
| Total Volatile Loss at 170°C | 0.4% (Maximum 0.6%) |
| pH Value | 6.0 - 8.0 (Neutral to slightly acidic) |
| Foreign Matter Content | 0.1% (Maximum 0.3%) |
| Particle Size | 5-10 microns (Maximum 25 microns) |
| Recommended Dosage | 0.2% - 0.5% by weight of RAP |
| Optimal Dosage (IIT Bombay) | 0.3% for 100% RAP mixes |
| Storage Temperature | 10-30°C in sealed containers |
| Shelf Life | 24 months from manufacture date |
Environmental Impact & Sustainability
RHEOFALT® HP AM delivers exceptional environmental benefits validated through comprehensive life cycle analysis. At 100% RAP content with 0.3% RHEOFALT® HP AM dosage, CO₂ emissions are dramatically reduced from 47.41 kg to 34.06 kg per metric ton of processed asphalt - a remarkable 28% reduction in carbon footprint. The environmental cost of RHEOFALT® HP AM itself (production, storage, and dosing) is just 2.71 kg CO₂ equivalent, making the net environmental benefit substantial. Being 100% renewable and bio-based from natural plant resins, it eliminates dependence on petroleum-derived rejuvenators. The technology enables up to 100% virgin bitumen replacement, conserving finite petroleum resources. By facilitating high RAP utilization, it reduces aggregate quarrying impacts including habitat destruction, energy consumption, and transportation emissions. Millions of tons of RAP are diverted from landfills annually, supporting circular economy principles. The product contributes to achieving green building certifications (LEED, IGBC), meets sustainable procurement requirements for government projects, and aligns with India's climate change commitments under the Paris Agreement. Environmental Cost Indicator (ECI) analysis shows significantly lower values for 100% RAP mixes with RHEOFALT® HP AM compared to conventional 50% RAP or virgin asphalt mixes.
Return on Investment (ROI) Analysis
RHEOFALT® HP AM delivers exceptional return on investment through multiple cost-saving mechanisms. Using 100% RAP in asphalt production significantly reduces virgin bitumen consumption (50-60 tons per 1000 metric tons of asphalt), minimizes virgin aggregate quarrying requirements, and lowers transportation costs from utilizing on-site RAP instead of importing virgin materials. Additional lifecycle benefits include 30-50% longer pavement service life reducing maintenance frequency and costs, reduced project carbon footprint enabling access to green financing and sustainability incentives, compliance with increasingly stringent environmental regulations, enhanced corporate sustainability credentials valuable for ESG reporting and stakeholder relations, and reduced virgin material price volatility risk by maximizing RAP utilization. The technology also enables competitive bidding advantages for tenders emphasizing lifecycle cost and sustainability, and facilitates meeting government mandates for minimum RAP utilization in road projects. Payback periods are typically very short, with cumulative benefits increasing substantially over multiple projects and years of implementation. Contact VUBS Corporation for detailed project-specific cost-benefit analysis, ROI calculations, and pricing information tailored to your specific requirements and application scenarios.
Handling and Safety Considerations
RHEOFALT® HP AM is a bio-polymer resin with low toxicity profile requiring standard chemical handling protocols. Use safety glasses, gloves, and protective clothing during handling. Ensure adequate ventilation in enclosed mixing facilities to maintain air quality. Avoid direct skin contact - rinse immediately with copious amounts of water if contact occurs. No special respiratory protection is required under normal ambient conditions. The product is non-volatile at room temperature and presents minimal inhalation hazard. In case of eye contact, rinse immediately with water for at least 15 minutes and seek medical attention. For detailed safety information including first aid measures, firefighting procedures, and accidental release measures, always consult the Material Safety Data Sheet (MSDS) available from VUBS Corporation. Personnel handling the product should be trained in proper chemical handling procedures and emergency response protocols.
Labelling
RHEOFALT® HP AM is classified as non-hazardous under most international chemical classification systems including the Globally Harmonized System (GHS) of Classification and Labelling of Chemicals. It is not classified as dangerous goods for transportation purposes under UN regulations, ADR/RID (road/rail transport in Europe), IMDG (maritime transport), or IATA (air transport). The product does not require hazard pictograms, signal words, or hazard statements typical of hazardous chemicals. However, proper identification labeling should include product name, manufacturer (BASF), supplier (VUBS Corporation), batch number, manufacturing date, and recommended storage conditions. GHS-compliant labels are provided with all shipments. The product meets Indian Standards (IS) requirements for road construction additives and is approved for use under Indian Roads Congress (IRC) specifications. BIS (Bureau of Indian Standards) certification is currently in application process. All containers are labeled with handling precautions, emergency contact information, and technical support details. For export shipments, labeling complies with destination country requirements. Customers should maintain proper inventory records including batch numbers for traceability and quality assurance purposes.
Storage and Shelf Life
Store RHEOFALT® HP AM at temperatures between 10-30°C in tightly sealed containers to maintain product integrity and prevent contamination. The product has a shelf life of 24 months from the manufacturing date when stored under recommended conditions. Containers should be made of compatible materials including HDPE (high-density polyethylene), steel, or fiberglass to prevent chemical interaction. Protect from direct sunlight and heat sources exceeding 60°C which may degrade the bio-polymer structure. The product is not freeze-thaw stable and must be maintained above 5°C at all times to prevent irreversible changes in viscosity and performance. Storage facilities should maintain clean conditions to prevent contamination - implement proper tank hygiene measures if storing in bulk tanks. Keep containers tightly closed when not in use, and ensure the headspace is minimized to reduce oxidation. Rotate stock on a first-in-first-out (FIFO) basis to ensure freshness. Storage areas should be well-ventilated, dry, and away from incompatible materials. Ground and bond containers during transfer operations to prevent static electricity buildup, although the product is not flammable at normal storage temperatures.
Technical Support and Availability
RHEOFALT® HP AM is a pure liquid resin additive which is easy to dose at normal ambient temperatures between 15-30°C without any heating requirement. When the climate is colder (below 15°C), dosing efficiency can be improved by gently warming the product to 15-20 degrees Celsius, which reduces viscosity and enhances flow characteristics while preserving the bio-polymer structure. Never heat above 60°C to prevent degradation.
The product can be added using three proven methods: (1) Direct addition into the pug mill of the hot mix asphalt plant during the mixing cycle, allowing 45-60 seconds of mixing time for uniform distribution; (2) Pre-blending with fresh virgin bitumen at 140-160°C before introducing RAP material, ideal for partial replacement scenarios; (3) Surface application to RAP stockpiles with 24-48 hours penetration time, followed by stockpile turning for distribution. CRITICAL APPLICATION GUIDANCE: When adding RHEOFALT® HP AM directly to RAP material, it MUST be added at the discharge end of the heating drum, NOT before material enters the drum, to prevent premature volatilization of the bio-polymer components at high temperatures.
As an authorized distributor of this technology in India, VUBS Corporation offers technical support services that may include detailed mix design assistance for optimizing RAP content and rejuvenator dosage, on-site application training for plant operators and quality control personnel, performance testing guidance, troubleshooting support for addressing field challenges, quality assurance protocols, specification compliance guidance for projects, and technical consultation as needed. Our team works in collaboration with BASF’s technical resources and can leverage IIT Bombay research data to support implementation of RHEOFALT® HP AM technology. Contact us to discuss your specific project requirements and explore how we can assist with product availability, technical guidance, and application support.
Frequently Asked Questions
What is RHEOFALT® HP AM and how is it different from conventional rejuvenators?
RHEOFALT® HP AM is a 100% renewable bio-polymeric rejuvenator that works by isolating and stabilizing the polar effect of asphaltenes in aged bitumen, rather than simply diluting them like conventional rejuvenators. This unique mechanism preserves the colloidal balance of the bitumen, enables 100% bitumen reusability without virgin material supplementation, and provides superior long-term performance. The technology has been validated through extensive research by IIT Bombay specifically for Indian RAP materials and road conditions, demonstrating enhanced penetration recovery, improved temperature susceptibility across India's extreme climate range, and significantly better fatigue and rutting resistance compared to conventional approaches.
What percentage of RAP can I use with RHEOFALT® HP AM?
RHEOFALT® HP AM enables up to 100% RAP content in asphalt mixes. The IIT Bombay validation study specifically tested and confirmed optimal performance at 100% RAP with 0.3% RHEOFALT® HP AM dosage, demonstrating that properties comparable to or better than virgin bitumen mixes can be achieved. However, the actual RAP content used in practice should be determined based on project specifications, local regulatory requirements, available RAP quality and characteristics, mix design objectives, and performance requirements. Common applications range from 40% RAP for conservative specifications to 100% RAP for sustainability-focused projects. VUBS Corporation provides comprehensive mix design support to determine the optimal RAP percentage for your specific application.
How much RHEOFALT® HP AM should I add to my asphalt mix?
The recommended dosage range is 0.2% to 0.5% by weight of RAP material. For most applications, 0.3% provides the optimal balance of performance and cost-effectiveness, as validated by IIT Bombay research for 100% RAP mixes. This dosage successfully restores aged bitumen properties to near-virgin levels. Severely aged RAP or RAP from harsh climatic exposure may require dosages up to 0.8% for complete rejuvenation. The optimal dosage for your specific application depends on RAP age and condition, original binder grade, degree of oxidation, target performance specifications, and climatic conditions. Always conduct laboratory trial mixes, perform performance testing (penetration, viscosity, DSR, MSCR), and validate field performance before full-scale implementation. VUBS Corporation provides technical support for dosage optimization based on your RAP characteristics and project requirements.
Can RHEOFALT® HP AM be used in cold weather or cold regions?
Yes, RHEOFALT® HP AM actually improves low-temperature performance of recycled asphalt pavements significantly. The bio-polymeric rejuvenation mechanism restores flexibility and relaxation properties to aged bitumen, enabling pavements to resist thermal cracking at temperatures down to -15°C. This makes it ideal for cold regions and seasonal temperature variations across India. For dosing the product itself in cold weather (ambient temperatures below 15°C), the viscosity can be reduced by gently warming RHEOFALT® HP AM to 15-20°C before dosing, which improves flow characteristics and ensures even distribution. Never heat above 60°C to preserve the bio-polymer structure. The product maintains its rejuvenating effectiveness across all climatic zones from Himalayan cold regions to tropical coastal areas, as validated by IIT Bombay's temperature susceptibility testing.
What are the environmental benefits of using RHEOFALT® HP AM?
RHEOFALT® HP AM delivers exceptional and quantified sustainability benefits. It is manufactured from 100% renewable bio-based natural plant resins, completely eliminating petroleum-derived components. Environmental impact studies demonstrate that using 100% RAP with 0.3% RHEOFALT® HP AM reduces CO₂ emissions from 47.41 kg to 34.06 kg per metric ton of asphalt - a remarkable 28% carbon footprint reduction. The technology enables up to 100% virgin bitumen replacement, conserving finite petroleum resources and reducing dependence on crude oil imports. High RAP utilization diverts millions of tons of waste asphalt from landfills annually, supporting circular economy principles. Reduced aggregate quarrying minimizes environmental impacts including habitat destruction, energy consumption, and dust emissions. The product supports achievement of green building certifications (LEED, IGBC), compliance with sustainable procurement policies, and contributes to India's climate commitments under international agreements. The Environmental Cost Indicator (ECI) for 100% RAP mixes with RHEOFALT® HP AM is significantly lower than conventional asphalt production methods.
Is RHEOFALT® HP AM approved for use in Indian road projects?
Yes, RHEOFALT® HP AM has been extensively validated through a comprehensive research collaboration with the Indian Institute of Technology (IIT) Bombay specifically for Indian RAP materials and road conditions. The study evaluated performance characteristics critical to Indian pavements including temperature susceptibility across India's extreme climate range (+65°C to -5°C), fatigue resistance under heavy traffic loading, rutting performance in hot climates, and aging resistance for long-term durability. The technology meets Indian Roads Congress (IRC) specifications for asphalt rejuvenators and is approved for use in government (NHAI, state PWD, PMGSY) and private road projects. While BIS (Bureau of Indian Standards) certification is currently in application process, the IIT Bombay validation and IRC compliance provide strong technical credibility. VUBS Corporation, as the exclusive all-India distributor, provides comprehensive technical support for specification compliance, mix design approval, quality control protocols, and project implementation guidance to ensure successful adoption in Indian infrastructure projects.
How should RHEOFALT® HP AM be added to the asphalt mix?
There are three proven application methods: (1) Direct Pug Mill Addition - Add RHEOFALT® HP AM directly into the hot mix plant pug mill during the mixing cycle. Heat RAP to standard mixing temperature (150-165°C), dose the rejuvenator, and mix for extended duration (45-60 seconds) to ensure uniform distribution. This is the most common method for production facilities. (2) Blending with Virgin Bitumen - Pre-mix RHEOFALT® HP AM with heated virgin bitumen (140-160°C) before introducing RAP material. This method is ideal for partial RAP replacement scenarios and ensures thorough distribution. (3) RAP Stockpile Treatment - Spray RHEOFALT® HP AM onto RAP stockpiles, allow 24-48 hours penetration time, turn the stockpile for distribution, then process through the hot mix plant. CRITICAL APPLICATION GUIDANCE: When adding directly to RAP, the rejuvenator MUST be applied at the discharge end of the heating drum, NOT before material enters the drum. Adding before the drum causes premature volatilization at high temperatures and reduces effectiveness. For cold weather (below 15°C), warm the product to 15-20°C for better flow. VUBS Corporation provides on-site application training and technical support to ensure optimal implementation.
Where can I purchase RHEOFALT® HP AM in India and what technical support is available?
RHEOFALT® HP AM is available ex-stock across India exclusively through VUBS Corporation, the authorized all-India representative and distributor for this BASF breakthrough technology. We maintain strategic inventory locations ensuring rapid delivery across all Indian states and union territories. Our comprehensive technical support services include: detailed mix design assistance and optimization for your specific RAP characteristics; dosage calculation and cost-benefit analysis for project planning; on-site application training for plant operators, supervisors, and QC personnel; performance testing using advanced laboratory equipment (penetration, viscosity, DSR, MSCR); quality assurance protocols and standard operating procedures; specification compliance guidance for government and private tenders; troubleshooting support for addressing field challenges; documentation support for approvals and certifications; and continuous technical consultation backed by BASF's global expertise and IIT Bombay research validation. Contact VUBS Corporation for immediate product availability confirmation, competitive pricing quotations, technical data sheets, safety documentation (MSDS), and customized implementation plans tailored to your road construction projects. Our experienced technical team is committed to ensuring successful adoption and optimal performance of RHEOFALT® HP AM technology in Indian infrastructure development.
Important Testing & Liability Disclaimer: The technical specifications and performance data presented herein are derived from controlled laboratory conditions and standardized testing environments. Actual performance may vary significantly based on application-specific conditions, formulation variables, environmental factors, and processing parameters. All customers are strongly advised to conduct comprehensive application testing and validation trials prior to commercial-scale production or project deployment. VUBS Corporation supplies products strictly on an "as-is" basis and expressly disclaims all liability for any direct, indirect, incidental, consequential, or punitive damages arising from product use, application, or performance. Customers assume full and sole responsibility for product suitability assessment, application testing, quality control, and all associated risks. Due to strong market demand and limited inventory availability, procurement decisions should be made expeditiously following successful validation testing. For technical consultation and sample procurement, please contact our team.
